X Series
Range
-
› Air flow-rates over 100,000 m³/h.
-
› High efficiency, up to 80%
-
› Low pressure drop; recommended ∆P 200 Pa.
-
› Max. differential pressure up to 2500 Pa.
-
› Max working temperature 90°C (silicone-free). Option up to 200°C.
Material characteristics
Aluminium
Aluminium is used in most applications, being resistant to corrosion, easy to machine, non-flammable and durable.
Aluminium with epoxy protection (Gold)
In environments with aggressive atmospheres, aluminium protected by a non-toxic, corrosion-resistant epoxy coating (AC - GOLD version) is recommended.
B·Blue (AB)
To reduce power consumption for cooling, the heat recovery unit can be incorporated into an indirect evaporative cooling system. For these applications, Recuperator has developed a new aluminium coating that improves system performance and ensures high resistance to corrosion. For further information, please see the B·Blue technical documentation.
Dimensions
| Typology | Model | B1xB1 | E1 | A1 | Fins spacing |
|---|---|---|---|---|---|
 | 07 - 08 - 09 10 - 11 - 12 | 705 - 805 - 905 1005 - 1105 - 1205 | 998 - 1139 - 1280 1421 - 1562 - 1705 | 2500 | from 3 to 8 |
 | 14 - 16 - 18 20 - 22 - 24 | 1410 - 1610 - 1810 2010 - 2210 - 2410 | 1994 - 2277 - 2560 2843 - 3125 - 3409 | 2500 | from 3 to 8 |
 | 27 - 30 33 - 36 | 2715 - 3015 3315 - 3615 | 3840 - 4264 4688 - 5112 | 2500 | from 3 to 8 |
Measurements in mm.
Maximum lengths can be divided into several modules according to steps and weights.
Options
Default
Available
Unvailable
Default Available Unvailable Default
Available
Unvailable
| F Series | A/B Series | E Series | X Series |
|---|
| F Series | A/B Series | E Series | X Series | ||
|---|---|---|---|---|---|
AZ Hips reduced by 1 mmAluminum side plates, made with reduced thickness, with smooth top and easy installation (slide-in), combined with CD option. This solution (prerogative of some models of the B series) allows to have a greater finned surface, which can be important in small spaces. These devices are also very light and easy to handle. |
|
|
|
|
|
PROFILES |
CD Special profile (combined with AZ and AR)It is possible to combine special head covers so that they can be quickly installed in the air handling units (slide-in). |
|
|
|
|
SEALING |
NS Silicon freeRecuperator devices are produced without the use of silicone. However, in some applications (for example, for high temperatures), in order to guarantee the sealing between air flows, it is necessary to use this sealant. |
|
|
|
|
SC Additional sealingOption that guarantees a greater seal between the two air flows. This option is recommended in particular applications such as hospitals, clean rooms, spray booths etc. |
|
|
|
|
|
SM Mechanical sealingStandard option produced during the stamping phase only for the F series. |
|
|
|
|
|
BY-PASSPDF |
BS Side bypass without damperOption that provides a side by-pass section without damper. |
|
|
|
|
BZ Bypass centrale senza serrandaOption that provides a central by-pass section without damper. |
|
|
|
|
|
BYPASS AND DAMPERPDF |
BP Lateral bypass with external control damperOption that includes a lateral by-pass section equipped with a damper with external control. |
|
|
|
|
VP Lateral bypass with painted damper external controlOption that includes a side by-pass section equipped with a painted damper with external control. |
|
|
|
|
|
BD Lateral bypass with internal control damperOption that provides a side by-pass section equipped with damper with internal control. |
|
|
|
|
|
BC Central bypass with external control damperOption that includes a central by-pass section equipped with a damper with external control. |
|
|
|
|
|
BE Central bypass with internal control damperOption that includes a central by-pass section equipped with a damper with internal control. |
|
|
|
|
|
FD Lateral bypass with damper without plastic parts and internal controlOption that includes a side by-pass section equipped with a damper without plastic parts and with internal control. |
|
|
|
|
|
XS High differential pressureReinforced plate for 3000Pa / 12inwc of pressure. Available only for F series model |
|
|
|
|
|
TV Epoxy protectionEpoxy protection for both corner profile and side plates against aggressive environments. Max temperature allowed 90°C. This option is usually associated with AC or AB fins. |
|
|
|
|
|
AR Side plateSide plate with fold and with smooth top and easy installation (slide-in). Lower limits than AE side plates. |
|
|
|
|
|
AF Selected Side platesSide plates, in case of limited space, can be selected (same construction with smaller dimensions). Compared to the AE, AF has lower limits for heat exchanger in one piece. Always 20mm (0.78in) of thickness |
|
|
|
|
